Recommended for controlling a projector, this circuit was found in documentation from the 80s. The circuit uses an optical coupler to control a triac. The sensor is a common phototransistor.
| Clique na imagem para ampliar |
Flip Flop Driven by Laser Pointer (CB24437E)
- Details
- Written by: Newton C. Braga
