Darlington Push-pull Stage (CB26252E)
- Details
- Written by: Newton C. Braga
This two-transistor amplifier stage was obtained from the Encyclopedia of Electronic Circuits Volume 5 of 1995. The input is high impedance, and the output is made at R3.
