This 1 kHz filter was found in the March 1997 issue of Electronics Now magazine. The circuit is applicable to any operational amplifier with a dual power source.
| Clique na imagem para ampliar |
Second Order High Pass Filter (CB25995E)
- Details
- Written by: Newton C. Braga
