Using the CMOS 4046 IC this motor control was found in November 1984 Radio Electronics magazine. The maximum motor current depends on the transistor and can reach more than 3 A as in this case.
DC Motor Control (CB24872E)
- Details
- Written by: Newton C. Braga
