The operating frequency of this circuit is 465 Hz and the input voltage is 12 VAC. The circuit is 65% efficient. We found it in a 1968 Motorola publication.
| Clique na imagem para ampliar |
12 V x 60 W inverter (CB7152E)
- Details
- Written by: Newton C. Braga
