This circuit produces sounds of 6 different notes depending on the keys activated. The circuit is from a Radio Electronics from May 1965. The transistor must be equipped with a heat radiator.
| Clique na imagem para ampliar |
6 Tone Horn (CB23654E)
- Details
- Written by: Newton C. Braga
