This oscillator generates a fixed frequency signal determined by C1 and C2. In the case of 1 nF, the signal will be 10 kHz for R1 and R2 15.8 k. These components can be changed to obtain other frequencies.
10 kHz oscillator (CB20349E)
- Details
- Written by: Newton C. Braga
