The frequency of this unijunction oscillator is determined by the crystal whose maximum frequency is 100 kHz. The unijunction can be 2N2646. The circuit is from 1970s documentation. Observe the signal amplitude and the high supply voltage.
Unijunction and XTAL Relaxation Oscillator (CB13854E)
- Details
- Written by: Newton C. Braga
