The circuit shown is from the National Semiconductor Linear Applications Handbook of 1994. using ADC0808. The circuit can handle data from up to 4 transducers with an 8-bit output.
| Clique na imagem para ampliar |
Transducers ADC Converter ADC0808 (CB14349E)
- Details
- Written by: Newton C. Braga
