Found in Motorola's 1967 documentation this circuit can use any general-purpose transistor. The signal should be applied to a good amplifier. The noise diode can be replaced with a common one.
| Clique na imagem para ampliar |
Cymbal Sound (CB6707E)
- Details
- Written by: Newton C. Braga
